SSL Setup for miniOrange PAM

To set up SSL for miniOrange PAM, please follow the steps below.

Step 1: Update Nginx Configuration

• Go to the PAM deployment folder.
• Navigate to: docker_utils > nginx > nginx.conf
• In this file:
• Change listen 80 to: listen 443 ssl;
• Inside the server section, add the following lines:

ssl_certificate /etc/nginx/ssl/<cert_file>.crt; #change the name of the .crt file

ssl_certificate_key /etc/nginx/ssl/<ke_file>.key; #change the name of the .key file

ssl_protocols TLSv1.2 TLSv1.3;

Step 2: Add SSL Certificate Files

• Inside the folder docker_utils > nginx , create a new folder named ssl: mkdir ssl.
• Place the SSL certificate files (.crt and .key) inside this ssl folder.

Step 3: Update docker-compose.yml

• Open the docker-compose.yml file at the PAM deployment folder.
• Under the nginx service section, add the following line under volumes:
./docker_utils/nginx/ssl:/etc/nginx/ssl

Step 4: Restart the Service

• Once all the above changes are completed, run the following command:
docker compose up -d nginx
• Your SSL setup will then be completed.
